Electric Elevators
Geared Traction Machines
Page 2
Return to elevatorbob's Electric Elevators
Return to elevatorbob's Elevator Pictures
Image 31
A very dirty geared machine - probably in an abandoned building
Image provided by: Neal Stubbs
I know more!
Image 32
Image provided by: Neal Stubbs
I know more!
Image 33
Installation circa 1946
Image provided by: Neil Barlow
I know more!
Image 34
A J & E Hall Ltd. machine
Image provided by: Will Rinkhum
I know more!
Image 35
The same J & E Hall Ltd. machine
Image provided by: Will Rinkhum
I know more!
Image 36
Image provided by: Will Rinkhum
I know more!
Image 37
An AC machine driving a...
Image provided by: Pablo Torres
I know more!
Image 38
Where's the rest of the building?
Image provided by: Paul Troy
I know more!
Image 39
An Otis flat-head machine...please note the shape of the motor
Image provided by: Rick Jensen
I know more!
Image 40
A basement machine installed in the pit - I believe it is an Otis machine
Image provided by: Rick Jensen
I know more!
Image 41
Another MAJOR trouble call!
Looks like another flat-head Otis motor
Image provided by: Ken Fowler
I know more!
Image 42
Part of the Mine Elevators collection of images
Image provided by: Jerry Taylor
I know more!
Image 43
Image provided by: Amos Lindsey
I know more!
Image 44
Machine brushes, commutator, armature, and field poles
Image provided by: Kenny Liftuer
I know more!
Image 45
More machine brushes, commutator, and armature
Image provided by: Kenny Liftuer
I know more!
Image 46
An Otis geared machine with a flat-head motor
Image provided by: Pablo Torres
I know more!
Image 47
Two geared machines and a gearless machine that have been cannibalized for parts and/or scrap metal
Image provided by: Gene Walker
I know more!
Image 48
A "green" machine
Image provided by: Gene Walker
I know more!
Image 49
A machine driven by what appears to be an AC motor - Melbourne, Australia
Image provided by: Jason Summers
I know more!
Image 50
A Montgomery machine
Image provided by: Jason Summers
I know more!
Image 51
A derelict machine
Image provided by: Wade Peet
I know more!
Image 52
Several derelict machines, motors, and parts...
the open machine in the right foreground appears to be a flat-head motor
Image provided by: Wade Peet
I know more!
Image 53
A derelict but stylized Otis set-up...
please note the common bedplate for the machine and motor-generator set.
Image provided by: Barton Willis
I know more!
Image 54
An old machine in an old hotel in Japan - the controller image is located here
Image provided by: Kenny Liftuer
I know more!
Image 55
Two large Otis machines...are we clear as to which way is up?!
Please note the extra care taken to guard the drive sheaves...this is unusual here in California.
An abandoned Kodak building in Toronto, Ontario, Canada
Image provided by: Surtin Pele
I know more!
Image 56
An Otis machine I have never seen in California
Image provided by: Surtin Pele
I know more!
Jerry Follen informs me that: "This looks like an Otis #1
machine with an internal/external gear arrangement. It looks like a single speed
AC motor and it definitely has an AC 'oil pot' brake. It is located somewhere in Missouri
as I can see the inspection tag on the side of the controller." Thank you Jerry!
Image 57
A Schindler machine in Brussels, Belgium - not usually seen in California (1 of 4)
Image provided by: Roi Lung
I know more!
Image 58
A close-up of the motor and the flywheel. (2 of 4)
Image provided by: Roi Lung
I know more!
Image 59
This appears to be the reversing switch but...I am not sure. (3 of 4)
Image provided by: Roi Lung
I know more!
Image 60
Looks like the coil, resistors, and contacts for the brake but...I am not sure. (4 of 4)
Image provided by: Roi Lung
I know more!
