Car Tops

Page 1

Return to elevatorbob's Elevator Pictures

Car Top
Image 1
A derelict elevator somewhere in Brussels, Belgium
It appears that the car gate/door slides around to the side of the enclosure.
Image provided by: Elgin Bishop
I know more!

Car Top
Image 2
Taking a closer look...is that a really loose suspension rope back there?
Image provided by: Nel Amery
I know more!

Car Top
Image 3
A car top leveling device or...a set of limit switches?
Image provided by: Brent Towers
I know more!

Car Top
Image 4
An interesting car door and door operator arrangement...
Image provided by: Brent Towers
I know more!

Car Top
Image 5
A car top guide rail oiler in China...
Checkout the smiling anime embossed into the unit...
Image provided by: Shu Hai Tai
I know more!

Car Top
Image 6
A corner-post arrangement - but what is he pointing at...
Image provided by: Chris Little
I know more!

Car Top
Image 7
This is why a corner-post arrangement is utilized - openings on adjacent sides...
Image provided by: Chris Little
I know more!

Car Top
Image 8
What do you think is going on here?
Image provided by: Jason Spears
I know more!

Car Top
Image 9
A derelict and rusty one...
Image provided by: Ceasar Ponchio
I know more!

Car Top
Image 10
A derelict car in Leipzig-Eutritzsch, Germany
Image provided by: Nick Nelson
I know more!

Car Top
Image 11
An old door operator...
Image provided by: Michael Brasher
I know more!

Car Top
Image 12
Another interesting door operator...
Image provided by: David H. Laidlaw
I know more!

Car Top
Image 13
Looks like a Dover car top...
Image provided by: David Coblentz
I know more!

Car Top
Image 14 (1 of 2)
The Bennett School in the Hudson Valley, New York, U.S.A.
Image provided by: David Senseman
I know more!

Car Top
Image 15 (2 of 2)
From inside the car...
Image provided by: David Senseman
I know more!

Car Top
Image 16
Looks like some pieces are missing...
Image provided by: Robert Haimes
I know more!

Car Top
Image 17
Quite a lot of GAL equipment...
Image provided by: Charles Hansen
I know more!

Car Top
Image 18
The Hotel Carpati in Bucharest, Romania
Image provided by: Pat Hanrahan
I know more!

Car Top
Image 19
Somewhere in Japan...
Please note - they are tied-off and there is a handrail...
Image provided by: Larry Yoshida
I know more!

Car Top
Image 20
A little preventive maintenance...
Image provided by: Elisha Sacks
I know more!

Car Top
Image 21
A Montgomery gate contact and operator...
Image provided by: Cecil Smith
I know more!

For Your Information

Lebras, from France, tells me with regards to the next 3 images:

"These pictures show an Otis European model installed from approximatively 1965-1975 in low and middle rise appartments and office buildings."

Load: 4/5/7/12 persons
Speed: AC 0.80 m/s - 1.00m/s
Speed: DC 1.50 m/s
Rise: 18 floors maximum

"These units were prefabricated in the Gien factory (France)
The car was delivered to the field completely assembled and fitted.
It was put in place mainly by field crane. We had to install only the ropes, traveller and selector tape (if provided).
The crosshead was made of bent iron sheet.

"The car was provided with:
Center-opening doors
A 955OT door operator with plastic pinion and door contacts around countershaft
U shaped door vane
Reopening door contact situated at the end of the operator arm near door vane.
Safeties coupling rod under the inspection box.

"This product was manufactured at many X 10,000 units."

Thank you Lebras!

Car Top
Image 22 (1 of 3)
Please note the selector tape, suspension rope terminations, and door operator...
Image provided by: Halis Ataksor
I know more!

Car Top
Image 23 (2 of 3)
The door operator...
Image provided by: Halis Ataksor
I know more!

Car Top
Image 24 (3 of 3)
Suspension rope terminations...
Image provided by: Halis Ataksor
I know more!

Car Top
Image 25
Stuck in the Ukraine...but that's a nice looking car top!
See more entrapped passengers here.
Image provided by: Ellis Chupkaug
I know more!
